High pressed graphite stem packing between double glands

•    Double nut locking with disc springs

•    Non-contamination execution

•    Heavy industrial stopper plate with locking device

•    Centring point on top of stem

•    Galvanised steel or stainless steel lever

•    Double D oversized stem

•    Triple stem packing

•    Low friction finishing stem

Stem seats : primary  PTFE seat, secondary graphite seat

•    Double antistatic execution (ATEX certified)

•    Anti blow-out stem (TA-luft certified)

•    ISO-mounting flange - DIN 3337

•    Complete machined ISO-top and flanges

•    PTFE stem packing with double O-rings

•    Pressure relieve hole in sleeve

•    Separate PTFE trust

•    Double cavity relieve seats

- 2-part, split house
- full flow, floating ball
- flange connection according to DIN 2501
- DIN 2526 - PN10 / 16/40 - pressure classes (exact selection of the following)
DN25-DN50: PN10 / 16/40 DN65-DN100: PN10 / 16 - Installation dimensions in accordance with DIN 3202-F4 / EN 558-1 series 14, or - With American standard flange connection: A150 - offer available on request, but the primary strength is DIN standard fittings
- with accessible carbon steel / stainless steel housing, stainless steel ball
- Housing can be:
Code: 44 - A216 WCB / 1.0619 - carbon steel Code: 66 - A351 CF8M / 1.4408 / SS316 Acid-resistant housing Standard seal - Teflon-PTFE; Code: T
Spherical stainless steel:
Code: 66 - A182 F304 / CF8 / 1.4401 - carbon steel double ball valve Code 66 - A182 F316 / CF8M / 1.4408 - Acid-resistant spherical ball valve RTFE, CTFE, MPTFE, PEEK - reinforced / composite seals optional
Size: between DN25 and DN100
